* 4X zoom 2.8-12mm vari-focus lens

* 1.5''Vandal proof body,IP67,IK10

* Support Audio, POE for optional

* IR range reach up to 45 Meters

* Pan/Tilt/Zoom,A-B scan,tour available

* Support Onvif; Support P2P function

* Support H.265/MJPEG compression,triple stream, video output

* Compatible with HIKVISION/DAHUA/Milestone/AEVISION/UC2 and AXXON platform

Camera
module NO	GW-IPD4X-200  2MP	GW-IPD4X-400 4MP	GW-IPD4X-200HS 2MP	GW-IPD4X-500 5MP
Video compression	H.265	H.265	H.265	H.265
Sensor	Mstat313e+2235	Mstat316DM+4689	3516CV300+Sony323	3516D+AR0521
Output pixel	1080p/20fps	2560*1440/20FPS	1080P, 30FPS/1080 P, 25FPS	2592x1944,15FPS/15FPS
Lens	Fixed lens4mm/ 4X=2.8-12mm	Fixed lens4mm/ 4X=2.8-12mm	4X f=2.8-12mm
D/N	IR-CUT
BLC	Auto
WB	Auto
S/N Ratio	>50dB
Dome
Communications Protocol	TCP/IP，HTTP， NTP，IGMP， DHCP，UDP，SMTP，RTP，RTSP，ARP，DDNS，DNS,PPPoE，P2P
Software Control	IE, CMS, Management Platform
audio compression	G711, PCM
Voice intercom	optional
Mobile View(optional)	Android  iPhone
Pan Range	0o-355o
Tilt  Range	0-70o
Pan Speed	0-25°/s
Tilt speed	0-20o/s
Preset Points	220
Guard Tours	3 groups ( each group 16 preset、dwell time and speed selectable)
Guard Points	Max.16 points, dwell time user selectable
AB scan range	any point in range:0o~70o and 0o-355o
AB scan speed	1-9 grades
Operating temperature	Outdoor: -30℃～+60℃
Operation menu	English
Auto Control IR LED	PWM
IR distance	up to 45 meters
Humidity	≤95% Non Condensing
Consumption	≤10W
Lightning Protection	Transient voltage 3000V
Related validation	IP66,CE,FCC,RoHs
Weight	NW:0.55KG GW:0.67KG

* 1.5''Vandal proof body,IP67,IK10

* Support Audio, POE for optional

* IR range reach up to 45 Meters

* Pan/Tilt/Zoom,A-B scan,tour available

* Support Onvif; Support P2P function

* Support H.265/MJPEG compression,triple stream, video output

* Compatible with HIKVISION/DAHUA/Milestone/AEVISION/UC2 and AXXON platform
