* Plug and Play,super easy operation.

* PLC eliminates the need for installation of dedicated network cabling.

* Support HomePlug AV,IEEE802.3,IEEE802.3u.

* Transmission distance over power line is upto 300m.

* The connection is stable & anti-jamming, without consuming network bandwidth.

* Data transmission speed is up to 200Mbps. HD video stream flows without delay.

Image Sensor	1/4" 1.0 Megapixel CMOS			1/3" 1.3 Megapixel CMOS			1/2.7" 2.0 Megapixel CMOS
Chipset Solution	OV9712 + Hi3518C			AR0130 + Hi3518C			OV2710 + Hi3516C
Resolution	1280×720 (720P)			1280×960 (960P)			1280×91080(1080P)
Minimum Illumination	3300mV/Lux-sec			5500mV/Lux-sec			5500mV/Lux-sec
S/N Ratio	39db			44db			44db
Frame Rate	1.0 Megapixel @ 25FPS			1.3 Megapixel @ 25FPS			2.0Megapixel @ 25FPS
Focus Mode	fixed
Day/Night	IR cut filter with auto switch, IR sensor.
Video Output	analog video out(optional), CVBS supported, PAL/NTSC (configurable)
Network	1 RJ45 Ethernet interface, 10/100M adaptation
Delay	Within 0.3S
Video Compression	H.264 compression ,dual stream ( 0.1M-6Mpbs adjustable)
Protocol	Protocols: RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP
Onvif	Support Onvif 2.2
User Permission	Multi-user Classification Management
Power/Current	DC 12V/1A
Consumption	3.0W
Lens	Board Lens 3.6mm/F2.0 (2M pixel)
IR Status	IR LED: ￠5X36pcs, IR Range: 30M
Dimension (mm)	112x84x70(mm)
Weight (g)	600g
Temperature	-10℃~ +60℃
Humidity	0%-90%RH,Without Condensation

4-CH   Full 1080P NVR
System	Main processor		High performance embedded microprocessor
	Operating system		Embedded LINUX OS
	System resource		Multi-channel real-time recording,  playback,  multi-channel multi-user network operation,  USB back up.
Video	Video standard		30 fps NTSC;25fps PAL
	Image encode		H.264(High Profile)
	Monitor quality		VGA, HDMI
	Playback quality		720P/ 960P/1080P
	Encode capability		4-ch  720P/ 960P/1080P real-time
	Decode capability		1*720P/ 960P/1080P real-time
	Motion detection		Each channel can set 192(16*12)detection area
Audio	Audio compression		N/A
	Bidirectional talk		N/A
Record and playback	Record mode		manual > alarm > motion detection> timing
	Local playback		1CH  playback
	Video search		time ; date ; event ; channel search
Storage and back up	Space occupation		Video：32G/day/channel
	Video storage		Local HDD  ; Network
	Back up mode		Network backup; USB backup; SATA imprint
Interface	Video input		4-ch
	Video output		1CH CVBS/BNC(1.0Vp-p, 75Ω), 1ch VGA, 1ch HDMI
	Alarm  Audio I/O		N/A
	Network port		RJ45 10M/100M self-adaptive Ethernet port
	PTZ control		N/A
	USB port		2*USB2.0
	HDD port		support 1 3TB SATA HDD inside
	Wireless port		N/A
Other	Power		DC  12V /2A
	Consumption		<15W(not including HDD)
	Temperature		0℃-＋55℃
	Humidity		10%－90%
	Atmosphere pressure		86kpa－106kpa
	Dimension		252 x 213 x 42mm(0.8u hight)
	Weight		1.5--1.8KG(not include HDD)
