CAMERA

Sensor

/4" 1.0MP OV9712; 1/3" 1.3MP AR0130; 1/2.5" 2.0MP SONY IM122

Min. Illumination

0.1Lux/F1.4

Electronic Shutter

Auto/Manual（1/25~1/10000）

Day/Night

Auto/B/W/Color/EXT ICR switching

Video Parameter

DWDR, Mirror, 3D Noise reduction, Sharpness/Lightness adjustable

IR Distance

20-30M( 2xIR Ⅲ LEDs

Lens

Optional (2M Pixels)  3.6/6.0mm

Lens Interface Type

M12

AUDIO/VIDEO COMPRESSION

Video Compression

H.264

Encoding

Dual-stream; Main stream: 1280×960 25fps/30fps

Sub Stream: 720×576 25fps/720×480 30fps

Effective Pixels

1280×960/1920*1080

Encoding System

Constant bit rate, Variable bit rate optional

Video Bit Rate

16Kbps-8000Kbps

Stream Type

Complex stream/Video stream

Audio Compression

G.711A

Audio Bit rate

64Kbps

NETWORK FUNCTION

Motion Detection

Can set a single detection zone, multi-level sensitivity can be set

Video Mask

Support 4 areas to mask

Screen Capture

Support JPEG format，max. resolution based on encoding resolution

Password Protection

Supported

Character Display

Supported（Channel name,Date）

Alarm Function

Video loss, Network disconnect, Tampering  alarm, Storage exception

Mobile Surveillance

Apple, Android

Protocol

TCP/IP,UDP,HTTP,DHCP,RTP/RTSP,DNS,DDNS,NTP,PPPOE,UPNP,SMTP

Port Protocol

ONVIF

INTERFACE

Analog Video Output

N/A

Network Interface

RJ45 10M/100M adaptive

GENERAL

Operating Conditions

-10°C ~ 55°C/0﹪-90﹪

IP Grade

IP66

Power Supply

DC12V /POE optional

Power Consumption

<5W (without IR LED)

Dimensions

105×104.8×263.1mm (4.13” × 4.13” × 10.38”)

Weight

About500g
